LUVOCOM® 3F PP CF 9928 BK
LUVOCOM 3F PP CF 9928 BK ist ein kohlefaserverstärktes PP-Filament für den 3D-Druck von starken und steifen Teilen und eignet sich zur kontinuierlichen Ableitung von statisch erzeugter Elektrizität.
FormFutura Luvocom 3F PP CF 9928 BK ist ein carbonfaserverstärktes PP (Polypropylen) auf Basis
3D-Drucker-Filament, das extrem steif und für industrielle Anwendungen entwickelt wurde. Luvocom 3F PP CF 9928 BK
ist ein 3D-Druckfilament mit niedriger Dichte, das gute mechanische Eigenschaften in Kombination mit hervorragenden Chemikalien aufweist
Widerstand und kontinuierliche elektrostatische Entladung (ESD) Eigenschaften.
Luvocom 3F PP CF 9928 BK zeichnet sich durch hervorragende Bedruckbarkeit mit verbesserter Schichthaftung aus, was es zu einem perfekten
3D-Druck-Filament für die Serienproduktion von starken, steifen und ESD-sicheren Endverbrauchsteilen mit extrem hoher Maßhaltigkeit.
Haupt Merkmale
-
Lehvoss Luvocom Luvocom 3F PP CF 9928 BK
-
ESD Oberflächenwiederstand von 107Ω
-
für den 3D-druck von starken, leichten und steifen Teilen
-
Gute chemische Beständigkeit
-
3D-Drucke mit hoher Maßhaltigkeit und erhöhter Schichthaftung
Anwendung
-
Medizinisch
-
Funktionale Prothesen
-
Dronen
-
End-Verbrauchs Teile
General printing guidelines *
Nozzle size: ≥ 0.4mm |
Layer height: ≥ 0.10mm |
Experience level: Expert |
Print temp: ± 220 - 230° C |
Fan speed: 10 - 50% |
Drying: 4-6h @80°C (max) |
Heat bed: ± 65 - 75° C |
Enclosure needed: No |
Adhesion: EasyFix Nr. III |
*) Above displayed settings are meant as guidance to find your optimal print settings.
These ranges in settings should work for most printers, but please do feel free to experiment
outside these parameters if you think it is suitable for your printer. There are a lot of different
type of printers, hot-ends and printer offset that it is extremely difficult to give an overall
one-size-fits-all setting.
Abrasiveness
Please be aware that this 3D printing filament contains a relatively high concentration of
extremely hard carbon fibers, which have an abrasive nature. In general these carbon fibers
will accelerate the nozzle-wear of brass nozzles, much faster than unfilled filaments.
We recommend to use nozzles from stainless steel or other hardened alloys.
Filament length
ρ: 1.00 g/cc |
0.2 Kg spool |
0.5 Kg spool |
|
|
|
Ø 1.75mm |
± 83m |
± 208m |
|
|
|
Ø 2.85mm |
± 31m |
± 78m |
|
|
|
Product export information
HS Code: 39169090 |
Description: Monofilament |
Country of origin: the Netherlands |
Compliance *
This filament is compliant to below-listed directives and regulations.
*) This declaration of conformity to directives and regulations is prepared according to
our present standard of knowledge and may be amended if new cognitions are available
and applies only for the above-described products.
