FreeScan UE11

As a blue laser handheld 3D scanner of the FreeScan series, FreeScan UE inherits the iconic features of "high precision" and
"stable repeatability". At the same time, ergonomic and lightweight device design makes it easier to hold and operate and offer
high-precision inspection solutions in metrology quality for the automotive, transport, aerospace industries, mold inspection,
power generation, machine manufacturing, etc.

Properties

High precision of the metrology class
Accuracy up to 0.02 mm, volume accuracy 0.02 mm + 0.04 mm / m.

Repeated measurement stability
When measuring the same part repeatedly, FreeScan UE provides consistent results and proves stability and reliability.

Portable and lightweight
The device weighs only 670 g, which makes scanning with the handheld easier and avoids fatigue caused by long working hours.

Large selection of material adjustments
Support for scanning black and reflective surfaces for a wider range of scanning applications.

High efficiency
The scanning area can reach 510 * 520mm, providing a larger field of view for a smoother and more efficient scanning experience.

Easy handling
User-friendly operating system with simple software setup and guidance through the entire workflow process so that users can easily
master the process.

Seamless docking with the inspection software
The scan data can be imported into inspection software such as Geomagic Control X, Verisurf Inspect and Einsense Q with one click,
increasing inspection efficiency.
