PolySmooth™ gives excellent printing characteristics, balanced mechanical properties,
and most importantly, “polishability” when exposed to common alcohols such as isopropyl alcohol or ethanol.
The Polysher™ was designed with a methodical approach from the electronics to the bolts used,With over 40 parts,
our designers made sure nothing was overlooked ensuring accurate designs and well thought out manufacturing.
Features
Polishable: The first 3D printable filament engineered for layer free post-processing. We have specifically
developed PolySmooth™ to work alongside the Polysher™ providing the solution to dramatically improve the
surface quality of 3D printed objects.
Intuitive & Easy To Use: Simply twist the dial to set the time, sit back and watch the magic happen.
Easy to Print: PolySmooth™ is compatible with all filament-based 3D printers and prints under similar conditions
as PLA. Featuring a wide printing temperature range, low odor and no heated bed required, PolySmooth™ is the
perfect companion to your desktop 3D printer.
Built-In Safety Features: The Polysher™ was designed with smart electronics,air tight seals and more.
Optimized for Support: We have taken our experience from PolySupport™ and engineered PolySmooth™
with the same support removal properties. Easily break away support from PolySmooth’s™ surface and once
your model is polished there is no scar left on the surface.
Low Costs: The Polysher™ is not only affordable but its running cost is incredibly low too.
Balanced Mechanical Properties: PolySmooth™ features well balanced mechanical properties, outperforming
ABS and PLA on most attributes , making it an ideal material for everyday 3D printing.
Warping Free: PolySmooth™ exhibits very minimal residual stress when printing which means almost no warping,
making it ideal for printing large parts.
Material Specs
Recommended Glass Transition Temp
~ 70 °C
Density
1.05 – 1.10 g/cm3
Diameters
1.75 mm or 2.85 mm
Tolerance
± 0.05 mm (Typical ~ ± 0.02 mm )
Recommended Printing Temp*
210 – 230 °C
Recommended Printing Speed*
40 – 90 mm/s
Recommended HBP1 (if equipped) Temp
Up to 70 °C
Note 1.HBP=Heated Build Plate *.Printing temperature and speed may vary
Spool Size
Specs & Operation
Technology
Nebulized Aerosol Polishing
Compatible Material
PolySmooth™
Polishing Liquid
Isopropanol or ethanol, 70% or above [90% or higher recommended]
Polishing Time
10 – 30 min typical (depending on part size)
Product Dimensions
230 x 270 x 370 mm
Maximum Polishable Part Size
150 mm (diameter) x 180 mm (height) cylinder [5.9 in (diameter) x 7.1 in (height)]
Operating Temperature
15 – 32 °C
Storage Temperature
0 – 38 °C
Power Requirements
100 – 240 V, 2A max, 50/60 Hz
Box and Machine Size
- PolySmooth - Material Data Sheet (185.44 KB)
- PolySmooth - Safety Data Sheet (345.97 KB)
