Raise3D Pro3

Raise3D Pro3

Raise3D Pro3 Plus

The Pro3 series comprises two dual extruder 3D printers: the Pro3 with a construction volume
of 300 x 300 x 300 mm and the Pro3 Plus with a construction volume of 300 x 300 x 605 mm.
Further developed from the award-winning Pro2 series, the Pro3 series offers improved usability,
higher effectiveness and industrial repeatability, which makes it the best choice in this segment
for every customer, 3D printing in agile production or in small series production used.

In terms of material compatibility, the Pro3 series is the printer with the widest potential in its
segment, capable of printing any filament extruding up to 300 ° C, including PLA, ABS, HIPS,
PC, TPU, TPE, NYLON, PETG , ASA, PP, PVA, glass fiber reinforced, carbon fiber reinforced,
metal filling and wood filling, among others. Customers can expect great results when using
Raise3D filaments as well as third party filaments approved under the Open Filament program.

The Pro3 series printers can be easily integrated into a production environment as they connect to
the Raise3D 3D printing software ecosystem, which includes the ideaMaker slicing software,
the ideaMaker open software template library and the management Includes RaiseCloud software.

Among the several new features, we highlight the following
improvements:

Exchangeable hotends:

The Pro3 series is equipped with an independent modular extruder with dual extrusion structure.
This allows the Pro3 series to print with a wide variety of filaments, while reducing clogging and
allowing easy disassembly and component replacement, reducing machine downtime.
The new interchangeable hotend system is ideal for users who frequently need to switch from
non-abrasive to abrasive materials that require different types of nozzles, or users who want to
print at higher speeds and require different nozzle sizes. They are equipped with a click and lock
mechanism that requires no tools, and each is uniquely identified for tracking and recording the
time the nozzles have been used.

Automatic bed leveling:

While the Pro2 series comes with a factory calibration that requires minimal or no calibration effort,
the Pro3 series goes a step further in ease of use and comes with automatic bed leveling.
The new automatic bed leveling feature is a relevant tool for those who use printers for production
purposes and want to implement a preventive maintenance program to ensure consistent quality of
the final printed parts. Automatic bed leveling minimizes calibration time and increases productivity.

Air Flow Manager

The Pro3 Series Air Flow Manager is located on the back of the printer, improves heat dissipation and
air circulation and creates a stable environment in the pressure chamber. Equipped with a
HEPA air filter, the Air Flow Manager can also filter and clean the air in the chamber.
As long as it works within the recommended temperature range, the Air Flow Manager
ensures the stability of the temperature in the chamber, which leads to better reproducibility of
high-quality results regardless of the external conditions.

EVE Smart Assistant

The Pro3 series has an integrated intelligent assistant system called EVE. Similar to 2D printing,
the EVE Assistant can guide users to pinpoint and fix problems that could affect the final print job.
It also has a feature that analyzes printer usage and reminds users of scheduled interventions to
ensure printer maintenance is carried out on time.
Raise3D is the first in its segment to introduce such a feature and take the usability of professional
3D printers to the next level.

Further improvements

Among the other improvements, we highlight the following:

• Flexible build plate that allows easy removal of 3D printed parts
• ​Z-axis bar stiffness has been increased by 75% for more stable performance
• Automatic detection so that when a door is opened the door will stop immediately, print and continue after the door has been closed
• Second generation power failure recovery to save the printing status in the event of a power failure and continue printing from the same location after power is restored.
• Light cable with digital temperature measurement
• HD camera with improved image quality and exposure sensitivity
